Compression Lug, Non-insulated, 4 AWG, 1/4 Stud"
SKU: 2190110

The ASI A5-M6 is a non-insulated Compression Lug that is UL Listed for 4 AWG, can be used with a 1/4 stud and can be crimped with one of the many tools available from ASI. The A-M Compression Lugs are constructed with an electrolytic copper which has been heat treated or annealed to strengthen the terminal especially between the crimp and tongue. The wire barrel of this 4-gauge crimp lug has a length that is optimized for ideal crimping and the inspection hole at the end allows you to check for proper insertion of the wire. This 4 AWG Compression Lug for use with a 1/4" stud is tin-plated to avoid oxidation making it ideal for most environments. Cordless hydraulic crimping tools B15MA, B35-50MA, B500A and B1500A are available from ASI to ensure that a proper crimp is accomplished during wire termination.

In Stock (1)

92.29 92.29 USD 92.29


Not Available For Sale

/Pack of 100 (0.92 / Each)

    This combination does not exist.

    Addtional Resources:
