Compression Lug, Non-insulated, 500-600 MCM, 3/4" stud
SKU: 2350350

The ASI A60-M20 is a non-insulated Compression Lug that is UL Listed for 500-600 MCM, can be used with a 3/4" stud and can be crimped with one of the many tools available from ASI. The A-M Compression Lugs are constructed with an electrolytic copper which has been heat treated or annealed to strengthen the terminal especially between the crimp and tongue. The wire barrel of this 500-600 MCM crimp lug has a length that is optimized for ideal crimping and the inspection hole at the end allows you to check for proper insertion of the wire. This 500-600 MCM Compression Lug for use with a 3/4" stud is tin-plated to avoid oxidation making it ideal for most environments. Cordless hydraulic crimping tools B15MA, B35-50MA, B500A and B1500A are available from ASI to ensure that a proper crimp is accomplished during wire termination.

Call for Availability

218.10 218.1 USD 218.10


Not Available For Sale

/Pack of 5
