2 Level Terminal Block, Exe Rated, DIN Rail Mount, With A Jumper Between the Upper and Lower Level, Screw Clamp, 24-10AWG

SKU: DS217

The DS217 is an ATEX approved EXi DIN rail 2 level blue terminal block, 6mm wide and UL rated at 20-12 AWG, 20A, 600V with an internal bridge connecting the upper and lower levels. The double level terminal block with 4 common connections reduces the required panel space by 50%. The DS217 Exi hazardous location din rail double level block is designed for jumpers or circuit bridges to be used on either or both levels. Labels or terminal block markers are available to easily label each of the 4 wiring positions on this double level din rail block.

Call for Availability

969.70 969.7 USD 969.70


Not Available For Sale

/Pack of 120 (8.08 / Each)
