12V DC Power Supply, 14 Amp, 115-230V AC Input, DIN Rail Mounted


The FLEX17012A is a space saving single-phase DIN rail power supply with compact dimensions that require less than 2.2 inches of rail space thereby saving valuable panel space. It provides 168 watts or 14 amps at 12 Vdc power using a wide range 115 to 230 volts AC input that makes it applicable for use in North America or anywhere else in the world. It has pluggable connections that will save time and money during and after installation. The high efficiency design of this 12V, 14A DIN rail power supply is 91% which provides for low dissipated power and a long reliable life. The FLEX17012A power supply features Overload, Over Temperature (Shut down and Automatic restart), Short Circuit (Hiccup Mode, Continuous Out Mode and Manual Reset) and Over Voltage Output Protection. It features a “Power Good” relay contact for remote indication. The FLEX17012A power supply is suitable for parallel connection applications.

Call for Availability

182.54 182.54 USD 182.54
