15 Position Pluggable Terminal Block, Terminal Block Connector, With Screw Locks, 5.08mm pitch, Green Housing Wire Entry On Polarization Side Of Plug, 24-12AWG

https://www.sourceasi.com/web/image/product.template/51532/image_1920?unique=8ab494a
SKU: MRT3P5.08-15FV

The MRT3P5.08-15FV is a 15 position pcb pluggable terminal block with screw clamp connections, screw locks, side wire entry and spacing of 5.08mm. This 15 position pluggable screw terminal block has the wire entry on the polarization side of the terminal block connector. The screw locks screw into the threaded inserts on the mating header for a secure, vibration free connection. The housing of this 15 position pluggable terminal block is green and UL94V0 rated and the metal bodies are a nickel plated copper alloy. The housing of this 15 position pcb mount screw terminal block connector is polarized to ensure correct mating to the header. UL ratings for this 15 position pluggable terminal block are 30-12 AWG, 12A, 300V.

Call for Availability

1,292.20 1292.2 USD 1,292.20

1,292.20

Not Available For Sale

/Pack of 250 (5.17 / Each)
  • Color

This combination does not exist.

Addtional Resources:


Specifications

Color Green
