SKU: NDB3100J450-1LSS1A0R
1 Pole, 50 Amp Panel Mount Circuit Breaker, Hydraulic Magnetic Circuit Breaker, UL1077
SKU: NDB3100J450-1LSS1A0R
1 Pole, 50 Amp Panel Mount Circuit Breaker, Hydraulic Magnetic Circuit Breaker, UL1077. The ASI UL1077 NDB3-100 Rack Mount, Panel Mount circuit breakers feature hydraulic magnetic operation, are available in 1-100 Amps, and have a voltage rating of AC250V with a 5kA breaking capacity.
Specifications
| Poles | 1 |
| Voltage | 250V AC |
| Amperage | 50 Amps |
| Trip Curve | AC Medium |
| Mounting Style | Panel/Rack Screw Mount |
| Wire Connection / Termination Type | Stud |
| UL | UL 1077 |
| Interrupting Capacity | 5 kA |
| Circuit Breaker Type | Hydraulic - Magnetic |
