1 Pole, 3A, 240V AC, 80V DC, Trip Curve: Medium, DIN Rail Mount-Hydraulic Magnetic, 18mm Width, UL1077

https://www.sourceasi.com/web/image/product.template/1876/image_1920?unique=64b0edd
SKU: NDB5-J43-1P

The ASI NDB5-J43-1P high density DIN rail miniature single pole AC circuit breaker is a hydraulic magnetic breaker rated at 3 amp 240 Vac . The UL 1077 supplemental protection circuit breaker is 300% factory tested to guarantee quality and reliability. The high density circuit breaker is 13 mm per pole and saves over 25% of space on your DIN rail compared to a 18 mm circuit breaker. The NDB5 circuit breaker features easy to wire screw clamp connections and mounts on the industry standard 35 mm DIN rail. The NDB5 series of circuit breakers can be used in most industrial applications since this model features general purpose trip curve characteristics.

In Stock (35)

18.39 18.39 USD 18.39

18.39

Not Available For Sale

/Each
  • Poles
  • Voltage
  • Voltage
  • Amperage
  • Mounting Style
  • UL

This combination does not exist.


Specifications

Poles 1
Voltage 80V DC, 240V AC
Amperage 3 Amps
Mounting Style DIN Rail Mounted
UL UL 1077
