0.5 Amp DC Circuit Breaker, 1 Pole, 80V DC UL1077, DIN Rail Mounted

https://www.sourceasi.com/web/image/product.template/1916/image_1920?unique=7ae6947
SKU: NDB5-Z4.5-1P

The ASI NDB5-Z4.5-1P is a 0.5 amp DIN rail mount DC circuit breaker rated at 80 Vdc. This DC MCB mini circuit breaker is used in general purpose industrial applications. The NDB5-Z DIN rail mount DC circuit breaker has a high 10kA interrupt capacity and medium trip curve. The NDB5-Z is a space saving DIN rail DC breaker as it measures only 13mm wide per pole, has touch safe screw clamp wiring, and black flame-resistant housing. This one pole high-density din rail dc circuit breaker is 300% factory tested guaranteeing quality and reliability. This .5 amp, 1 pole DIN rail DC circuit breaker is the ideal choice for when space is at a premium in your panel.

17.17 17.17 USD 17.17

17.17

Not Available For Sale

/Each
  • Poles
  • Voltage
  • Amperage
  • Trip Curve
  • Mounting Style
  • Width
  • UL
  • Interrupting Capacity
  • Circuit Breaker Type

This combination does not exist.


Specifications

Poles 1
Voltage 80V DC
Amperage 0.5 Amps
Trip Curve Medium Delay/Z4
Mounting Style DIN Rail Mounted
Width 13 mm
UL UL 1077
Interrupting Capacity 10 kA
Circuit Breaker Type Hydraulic - Magnetic
