12 Amp Mini DC Circuit Breaker, 2 Pole, Medium Trip Curve, 80V DC, DIN Rail Mounted
SKU: NDB5-Z412-2P
The ASI NDB5-Z412-2P is a two pole 12 amp DC circuit breaker that mounts on a DIN rail and is rated at 80 Vdc. This DC mcb mini circuit breaker is used in general purpose industrial applications. The NDB5-Z DIN rail mount DC circuit breaker has a high 10kA interrupt capacity and medium trip curve. The NDB5-Z is a space saving DIN rail DC breaker as it measures only 13mm wide per pole and it has touch safe screw clamp wiring, and a black flame-resistant housing. This two pole high-density din rail dc circuit breaker is 300% factory tested guaranteeing quality and reliability. This 12 amp, 2 pole DIN rail DC circuit breaker is the ideal choice for when space is at a premium in your panel.
Specifications
| Poles | 2 |
| Voltage | 80V DC |
| Amperage | 12 Amps |
| Trip Curve | Medium Delay/Z4 |
| Mounting Style | DIN Rail Mounted |
| Width | 26 mm |
| UL | UL 1077 |
| Interrupting Capacity | 10 kA |
| Circuit Breaker Type | Hydraulic - Magnetic |
