20 Amp, 1 Pole, 80V DC, Trip Curve: C, DIN Rail Mount-Hydraulic-Magnetic Circuit Breaker, UL1077
SKU: NDB5-Z420-1P
The ASI NDB5-Z420-1P 20 amp DC circuit breaker rated at 80 Vdc. This miniature circuit breaker is used in general purpose industrial applications. It has a large 10kA interrupt capacity and medium trip curve. It measures only 13mm wide per pole, has touch safe screw clamp wiring, and black flame-resistant housing. This high-density circuit breaker is 300%factory tested guaranteeing quality and reliability. This DC circuit breaker is the ideal choice for when space is at a premium in your panel.
Call for Availability
Specifications
| Amperage | 20 Amps |
| Poles | 1 |
| Trip Curve | C Trip Curve (Medium) |
| Breaker Mounting | 35mm DIN Rail |
| UL | UL 1077 |
