32 Amp Mini DC Circuit Breaker, 1 Pole, 80V DC, UL1077, DIN Rail Mounted
SKU: NDB5-Z432-1P
The ASI NDB5-Z432-1P is a one pole 32 amp DC circuit breaker that mounts on a DIN rail and is rated at 80 Vdc. This DC mcb mini circuit breaker is used in general purpose industrial applications. The NDB5-Z DIN rail mount DC circuit breaker has a high 10kA interrupt capacity and medium trip curve. The NDB5-Z is a space saving DIN rail DC breaker as it measures only 13mm wide per pole and it has touch safe screw clamp wiring, and a black flame-resistant housing. This one pole high-density din rail dc circuit breaker is 300% factory tested guaranteeing quality and reliability. This 32 amp, 1 pole DIN rail DC circuit breaker is the ideal choice for when space is at a premium in your panel.
In Stock (8)
Specifications
| Voltage | 80V DC |
| Amperage | 32 Amps |
| Trip Curve | C Trip Curve |
| Mounting Style | DIN Rail Mounted |
| UL | UL 1077 |
