48 Volt DIN Rail Power Supply, 48Vdc, 50A Out, out 3-Phase 340-550Vac Input

The XCSG2401D is a three phase input 50A, 48V DIN rail mounted power supply with an internal microprocessor that controls many functions of the unit and which can be programmed by the customer. It also features very compact dimensions to save valuable panel space. It provides 2400 Watts or 50 Amps of 48Vdc power making it ideal for use with DC motors. A three phase wide range 340 to 550Vac input that makes it applicable for use in North America or anywhere else in the world. The high efficiency design of this 24V, 100A DIN rail power supply is greater than 93% which provides for low dissipated power and a long reliable life. It is cULus508 Listed and has features such as LED status indication, short circuit, over temperature, input and output overvoltage protection. The overload limit for the XCSG2401D is 75 Amps for greater than 5 seconds. The high outrush of this model makes it ideal in applications where heavy loads are powered. With a front panel display and easy to use programming keys the user can program numerous functions such as remote shutdown, remote sensing, battery charge temperature, output protection, temperature control, and more. An auxiliary 12Vdc is also available and wired through the pluggable multi-function connector.
