170V DC DIN Rail Power Supply, 14A Output, 3-Phase 340-550V AC Input,


The XCSG2401R is a 3-Phase DIN Rail Mounted Power Supply with Microprocessor for use with DC Motors. The Output is 170V DC, 2400 Watts, 14 Amps and Input is 340 to 550V AC making it suitable for use in North America as well as other countries. The high efficiency design of greater than 92% provides for low dissipated power and a long reliable life. It is cULus 508 Listed and has features such as LED status indication, short circuit, over temperature, input and output overvoltage protection. The overload limit for the XCSG2401R is 21A for greater than 5 seconds. The high outrush of this model makes it ideal in applications where heavy loads are powered. With a front panel display and easy to use programming keys the user can program numerous functions such as remote shutdown, remote sensing, battery charge temperature, output protection, temperature control, and more. An auxiliary 12V DC is also available and wired through the pluggable multi-function connector.

Call for Availability
