72VDC 6.6A DIN Rail Power Supply | 480W | 60-81V Adjustable | 85-264VAC | UL508 | XCSL1480W072VAA

The XCSL1480W072VAA is a 480W industrial DIN rail power supply providing
72VDC nominal output at 6.6A. Its wide 60-81VDC adjustable output range makes
it particularly well suited for 72VDC motor drives, stepper drives, motion
control systems, industrial machinery, and other equipment requiring
higher-voltage DC power.

The power supply accepts universal 85-264VAC single-phase input as well as
100-370VDC input, allowing it to operate from common 120VAC and 230VAC
industrial power systems. It provides active power factor correction, high
overload capability, DC OK status indication, a dry-contact alarm output, and
protection against short circuit, overload, overtemperature, and input/output
overvoltage.

WHAT PROBLEM DOES THIS SOLVE?
Many industrial motion-control applications require substantially more DC
voltage than standard 24VDC or 48VDC control power supplies provide.

The XCSL1480W072VAA delivers regulated 72VDC power for motor drives and other
high-voltage DC loads from standard 120VAC or 230VAC input. Its adjustable
60-81VDC output also allows the supply voltage to be matched to the operating
requirements of the connected drive or equipment.

KEY FEATURES & BENEFITS
• 72VDC Nominal Output for Motion Control and Higher-Voltage DC Loads
• 6.6A Continuous Output at 50°C Provides up to 480W of DC Power
• Adjustable 60-81VDC Output Supports a Wide Range of 72V Applications
• Universal 85-264VAC Input Supports 120VAC and 230VAC Power Systems
• 100-370VDC Input Provides Additional Installation Flexibility
• High Overload Capability Helps Start Demanding Industrial Loads
• DC OK LED and Dry-Contact Alarm Provide Power Supply Status
• Active PFC Provides Power Factor Greater Than 0.99
• Parallel Operation Supports Applications Requiring Additional Capacity
• UL508 Safety Standard Supports Industrial Control Applications

The current manufacturer specification gives 6.6A continuous output at 50°C,
7.5A overload limiting with up to 9A constant current, and an 18A short-circuit
peak for 100ms.

APPLICATIONS
• Stepper Motor Drives and Integrated Stepper Motors
• Servo and Motion Control Systems
• Industrial Motor Drives Requiring 72VDC Power
• CNC and Machine Automation Equipment
• Robotics and Automated Machinery
• Material Handling and Packaging Equipment
• Industrial Control Panels
• Higher-Voltage DC Equipment and Instrumentation

WHY CHOOSE THIS PRODUCT?
The XCSL1480W072VAA fills an important gap between standard 48VDC control
power and larger high-voltage power systems. Its 60-81VDC adjustment range
provides significantly more flexibility than a fixed 72V supply and allows
the output to be matched to the voltage requirements of a motion controller,
motor drive, or other DC load.

Its 480W output, high overload capability, universal AC input, alarm contact,
and industrial protection features make it particularly useful for machine
builders and motion-control applications where a conventional 24VDC or 48VDC
DIN rail power supply cannot provide the required bus voltage.

COMPETITIVE ALTERNATIVE
Looking for an alternative to Applied Motion PS480D72?

The XCSL1480W072VAA is a 72VDC, 480W DIN rail power supply for industrial
motion-control and automation applications. It provides a similar power class
and application profile, with a wider 60-81VDC adjustment range.
